LPMS-B2: 9-Axis Inertial Measurement Unit (IMU) with Bluetooth 2.1 and 4.1 Connectivity

US$ 249

Category:

Description

The LP-RESEARCH Motion Sensor Bluetooth version 2 (LPMS-B2) is a miniature wireless inertial measurement unit (IMU) / attitude and heading reference system (AHRS). The unit is very versatile, performing accurate, high-speed orientation and relative displacement measurements. By the use of three different MEMS sensors (3-axis gyroscope, 3-axis accelerometer and 3-axis magnetometer) low-drift, low-latency orientation data around all three axes is acquired. Additionally, temperature and barometric pressure sensors allow accurate determination of the unit’s altitude. LPMS-B2 communicates with a host system via Bluetooth Classic 2.1 or Low Energy 4.1 connection. Multiple LPMS-B2 units can be connected simultaneously to one host system (7 units maximum on Windows/Android), reaching transmission rates of up to 400Hz.

The unit contains a 32-bit digital signal processor capable of running all calculations on-board in real-time. For more information on our sensor fusion method please refer to the IMUcore description.

See the LPMS-B2 product pages at LP-RESEARCH for more detailed information.

PACKAGE CONTENTS

1 x LPMS-B2 sensor
1 x Micro USB cable
1 x User guide card
1 x Warranty & support (1 year)

NOTE: Please note that import duties, taxes, and charges are not included in the item price or shipping cost. Please contact us for orders over 50 pieces.
